Universal Bench Gauge

The addition of the Bowers supporting table and location feet transforms the Universal Gauge into an extremely flexible bench mounted gauge. Even greater speed of operation can be achieved in this format, ideal for the rapid gauging of batch parts etc. Higher accuracy can be realised in this configuration, aided by the added stability afforded by the addition of location feet.

Features

• Universal Bench Gauge for fast accuratemeasurement of internal and external dimensions
• Measuring range with table:
  Internal 10-100mm (0.4-4”)
  External 0-90mm (0-3.5”)
  Larger sizes, to 1000mm plus can be measured using two tables
• Measuring range without table:
  Internal 10-1000mm plus
  External 0-1000mm plus
• Large range of accessories available
• Digital readout options
• Large range of accessories available for Internal and External measurement of: Diameters, Grooves, Threads, Splines/Gears, Shallow spigots and Recesses, Tapers. Can also be used to check Lengths, Hole Centres, Concentricity and Rolling Gear Tests
• Digital readout option with:
  • 0.01/0.001mm resolution
  • Min/Max hold
  • Inch/Metric conversion
  • Preset memory
  • RS232 output for SPC
• Other readout options are:
  • Linear transducers and readout display
  • Dial gauge for comparative measurements



  Code	Size
  TGUA023	Bench Stands
  TGUA024	Table & Mountings
